Product Features
- Enhanced Energy Output: Delivers 8% more energy, optimizing ignition efficiency for improved vehicle performance.
- Reliable Performance: Designed for stability under various conditions, ensuring consistent ignition output.
- Durability Assured: Engineered to meet Toyota’s high standards, ensuring longevity even under high-performance usage.
Ignition Coil Test Results
1. Static Test
Test conditions: Indoor temperature 23±5°C, Relative humidity 60%
| Sample No. | Primary Resistance (Ω) | Secondary Resistance (kΩ) | Primary Inductance (mH) | Secondary Inductance (H) | Result |
|---|---|---|---|---|---|
| OEM Coil 1# | N/A | N/A | N/A | N/A | Test Passed |
| SXTH Element Coil #1 | N/A | N/A | N/A | N/A | Test Passed |
2. Dynamic Property Test
Test conditions: Rated operational voltage 14±0.1V, Charging time: 3.0ms, Discharge frequency: 50Hz
| Sample No. | Primary Current (A) | Secondary Peak Voltage (KV) | Discharge Time (ms) | Discharge Current (mA) | Ignition Energy (mJ) | Result |
|---|---|---|---|---|---|---|
| OEM Coil 1# | 10 | 37 | 1.2 | 80 | 48 | Pass |
| SXTH Element Coil #1 | 10 | 37 | 1.3 | 80 | 52 | Pass |
- 1.6T GR Corolla G16E-GTS
- 2.4T Toyota T24A-FTS
